FRDM-MCXA577

Overview

FRDM-MCXA577 is a compact and scalable development board for rapid prototyping of MCX A577 MCUs. They offer industry standard headers for easy access to the MCUs input/output (I/O), integrated open-standard serial interfaces, external flash memory and an onboard MCU-Link debugger.

Hardware

  • MCX-A577 Arm Cortex-M33 microcontroller running at 12MHz

  • 2048KB dual-bank on chip Flash

  • 640 KB RAM

  • 2x FlexCAN with FD, 1x RGB LED, 3x SW buttons

  • Ethernet: on-SoC 10BASE-T1S PHY, or 10/100 Mbit external PHY over MII

  • On-board MCU-Link debugger with CMSIS-DAP

  • Arduino Header, SmartDMA/Camera Header, mikroBUS

For more information about the MCX-A577 SoC and FRDM-MCXA577 board, see:

Supported Features

The frdm_mcxa577 board supports the hardware features listed below.

on-chip / on-board
Feature integrated in the SoC / present on the board.
2 / 2
Number of instances that are enabled / disabled.
Click on the label to see the first instance of this feature in the board/SoC DTS files.
vnd,foo
Compatible string for the Devicetree binding matching the feature.
Click on the link to view the binding documentation.

frdm_mcxa577/mcxa577 target

On-target memory for this board target: 512 KiB of RAM, 2 MiB of Flash.

Type

Location

Description

Compatible

CPU

on-chip

ARM Cortex-M33F CPU1

arm,cortex-m33f

ADC

on-chip

LPC LPADC11

nxp,lpc-lpadc

CAN

on-chip

NXP FlexCAN CANFD controller11

nxp,flexcan-fd

Clock control

on-chip

LPC SYSCON & CLKCTL IP node1

nxp,lpc-syscon

Clock monitor

on-chip

NXP Frequency Measurement (FREQME) module1

nxp,freqme

Comparator

on-chip

NXP Low Power Comparator (LPCMP)1

nxp,lpcmp

Counter

on-chip

NXP MCUX Standard Timer/Counter14

nxp,lpc-ctimer

on-chip

NXP LPTMR1

nxp,lptmr

on-chip

NXP Wake Timer1

nxp,wake-timer

CRC

on-chip

NXP CRC device1

nxp,crc

DAC

on-chip

NXP MCUX LPDAC11

nxp,lpdac

DMA

on-chip

NXP SmartDMA controller1

nxp,smartdma

on-chip

NXP MCUX EDMA controller11

nxp,mcux-edma

EDAC

on-chip

NXP Error Injection Module1

nxp,eim

on-chip

NXP Error Reporting Module1

nxp,erm

ESPI

on-chip

NXP MCX A series eSPI target controller1

nxp,espi

on-chip

NXP MCX A series eSPI Target Attached Flash (TAF) controller1

nxp,espi-taf

Ethernet

on-chip

NXP ENET QOS Ethernet Controller1

nxp,enet-qos

on-chip

Synopsys DesignWare MAC MDIO controller1

snps,dwmac-mdio

on-board

Generic MII PHY1

ethernet-phy

on-chip

Synopsys DesignWare MAC PTP (Precision Time Protocol) Clock1

snps,dwmac-ptp-clock

on-chip

NXP 10BASE-T1S PHY support1

nxp,t1s-phy

Flash controller

on-chip

NXP MSF1 Flash Memory Module (FMU)1

nxp,msf1

GPIO & Headers

on-chip

Kinetis GPIO6

nxp,kinetis-gpio

on-board

GPIO pins exposed on NXP LCD 8080 interface (e.g., used on LCD-PAR-035 panel)1

nxp,lcd-8080

on-board

GPIO pins exposed on Arduino Uno (R3) headers1

arduino-header-r3

Hardware information

on-chip

NXP LPC 128-bit Unique identifier1

nxp,lpc-uid

I2C

on-chip

NXP LPI2C controller23

nxp,lpi2c

I3C

on-chip

NXP MCUX I3C controller13

nxp,mcux-i3c

Input

on-chip

NXP TSI V6 Touch Sensing Input Device1

nxp,tsi-input

on-board

Group of GPIO-bound input keys1

gpio-keys

Interrupt controller

on-chip

ARMv8-M NVIC (Nested Vectored Interrupt Controller)1

arm,v8m-nvic

LED

on-board

Group of GPIO-controlled LEDs1

gpio-leds

MIPI-DBI

on-chip

NXP FlexIO LCD controller1

nxp,mipi-dbi-flexio-lcdif

Miscellaneous

on-chip

NXP FlexIO controller1

nxp,flexio

MMU / MPU

on-chip

ARMv8-M MPU (Memory Protection Unit)1

arm,armv8m-mpu

MTD

on-board

NXP FlexSPI NOR1

nxp,imx-flexspi-nor

on-board

Flash node2

soc-nv-flash

on-board

Fixed partitions of a flash (or other non-volatile storage) memory1

fixed-partitions

MUX

on-chip

NXP INPUTMUX peripheral binding1

nxp,inputmux

Pin control

on-chip

NXP PORT Pin Controller6

nxp,port-pinmux

on-chip

NXP PORT Pin Controller1

nxp,port-pinctrl

Power management

on-chip

NXP Smart Power Switch (VBAT)1

nxp,vbat

on-chip

NXP Core Mode Controller (CMC)1

nxp,cmc

on-chip

NXP System Power Control (SPC)1

nxp,spc

Power domain

on-chip

This power domain will Turn On and Off devices when transitioning in and out a specified Power State1

power-domain-soc-state-change

PWM

on-chip

NXP Flexio PWM controller1

nxp,flexio-pwm

Regulator

on-chip

NXP SPC buffered bandgap output1

nxp,spc-bandgap-buffer

Reset controller

on-chip

NXP MRCC Peripheral reset controller1

nxp,mrcc-reset

RNG

on-chip

Kinetis TRNG (True Random Number Generator)1

nxp,kinetis-trng

RTC

on-chip

IRTC1

nxp,irtc

Sensors

on-chip

NXP LPADC_TEMP40 temperature sensor1

nxp,lpadc-temp40

on-board

NXP P3T1755 digital temperature sensor connected to I3C bus1

nxp,p3t1755

Serial controller

on-chip

NXP LPUART24

nxp,lpuart

SPI

on-chip

NXP LPSPI controller15

nxp,lpspi

on-chip

NXP FlexSPI controller1

nxp,imx-flexspi

SRAM

on-chip

Generic on-chip SRAM1

mmio-sram

Timer

on-chip

ARMv8-M System Tick1

arm,armv8m-systick

on-chip

NXP OS Timer on i.MX-RT5xx/6xx1

nxp,os-timer

USB

on-chip

NXP EHCI USB device mode1

nxp,ehci

on-chip

NXP EHCI USB host controller1

nxp,uhc-ehci

on-chip

NXP USB High Speed PHY1

nxp,usbphy

Watchdog

on-chip

LPC Windowed Watchdog Timer11

nxp,lpc-wwdt

on-chip

NXP External Watchdog Monitor1

nxp,ewm

Wakeup Controller

on-chip

NXP Wakeup Unit (WUU) acting as a Wakeup Controller (WUC)1

nxp,wuc-wuu

frdm_mcxa577/mcxa577/mii target

On-target memory for this board target: 512 KiB of RAM, 2 MiB of Flash.

Type

Location

Description

Compatible

CPU

on-chip

ARM Cortex-M33F CPU1

arm,cortex-m33f

ADC

on-chip

LPC LPADC11

nxp,lpc-lpadc

CAN

on-chip

NXP FlexCAN CANFD controller11

nxp,flexcan-fd

Clock control

on-chip

LPC SYSCON & CLKCTL IP node1

nxp,lpc-syscon

Clock monitor

on-chip

NXP Frequency Measurement (FREQME) module1

nxp,freqme

Comparator

on-chip

NXP Low Power Comparator (LPCMP)1

nxp,lpcmp

Counter

on-chip

NXP MCUX Standard Timer/Counter14

nxp,lpc-ctimer

on-chip

NXP LPTMR1

nxp,lptmr

on-chip

NXP Wake Timer1

nxp,wake-timer

CRC

on-chip

NXP CRC device1

nxp,crc

DAC

on-chip

NXP MCUX LPDAC2

nxp,lpdac

DMA

on-chip

NXP SmartDMA controller1

nxp,smartdma

on-chip

NXP MCUX EDMA controller11

nxp,mcux-edma

EDAC

on-chip

NXP Error Injection Module1

nxp,eim

on-chip

NXP Error Reporting Module1

nxp,erm

ESPI

on-chip

NXP MCX A series eSPI target controller1

nxp,espi

on-chip

NXP MCX A series eSPI Target Attached Flash (TAF) controller1

nxp,espi-taf

Ethernet

on-chip

NXP ENET QOS Ethernet Controller1

nxp,enet-qos

on-chip

Synopsys DesignWare MAC MDIO controller1

snps,dwmac-mdio

on-board

Generic MII PHY1

ethernet-phy

on-chip

Synopsys DesignWare MAC PTP (Precision Time Protocol) Clock1

snps,dwmac-ptp-clock

on-chip

NXP 10BASE-T1S PHY support1

nxp,t1s-phy

Flash controller

on-chip

NXP MSF1 Flash Memory Module (FMU)1

nxp,msf1

GPIO & Headers

on-chip

Kinetis GPIO6

nxp,kinetis-gpio

on-board

GPIO pins exposed on NXP LCD 8080 interface (e.g., used on LCD-PAR-035 panel)1

nxp,lcd-8080

on-board

GPIO pins exposed on Arduino Uno (R3) headers1

arduino-header-r3

Hardware information

on-chip

NXP LPC 128-bit Unique identifier1

nxp,lpc-uid

I2C

on-chip

NXP LPI2C controller23

nxp,lpi2c

I3C

on-chip

NXP MCUX I3C controller13

nxp,mcux-i3c

Input

on-chip

NXP TSI V6 Touch Sensing Input Device1

nxp,tsi-input

on-board

Group of GPIO-bound input keys1

gpio-keys

Interrupt controller

on-chip

ARMv8-M NVIC (Nested Vectored Interrupt Controller)1

arm,v8m-nvic

LED

on-board

Group of GPIO-controlled LEDs1

gpio-leds

MIPI-DBI

on-chip

NXP FlexIO LCD controller1

nxp,mipi-dbi-flexio-lcdif

Miscellaneous

on-chip

NXP FlexIO controller1

nxp,flexio

MMU / MPU

on-chip

ARMv8-M MPU (Memory Protection Unit)1

arm,armv8m-mpu

MTD

on-board

NXP FlexSPI NOR1

nxp,imx-flexspi-nor

on-board

Flash node2

soc-nv-flash

on-board

Fixed partitions of a flash (or other non-volatile storage) memory1

fixed-partitions

MUX

on-chip

NXP INPUTMUX peripheral binding1

nxp,inputmux

Pin control

on-chip

NXP PORT Pin Controller6

nxp,port-pinmux

on-chip

NXP PORT Pin Controller1

nxp,port-pinctrl

Power management

on-chip

NXP Smart Power Switch (VBAT)1

nxp,vbat

on-chip

NXP Core Mode Controller (CMC)1

nxp,cmc

on-chip

NXP System Power Control (SPC)1

nxp,spc

Power domain

on-chip

This power domain will Turn On and Off devices when transitioning in and out a specified Power State1

power-domain-soc-state-change

PWM

on-chip

NXP Flexio PWM controller1

nxp,flexio-pwm

Regulator

on-chip

NXP SPC buffered bandgap output1

nxp,spc-bandgap-buffer

Reset controller

on-chip

NXP MRCC Peripheral reset controller1

nxp,mrcc-reset

RNG

on-chip

Kinetis TRNG (True Random Number Generator)1

nxp,kinetis-trng

RTC

on-chip

IRTC1

nxp,irtc

Sensors

on-chip

NXP LPADC_TEMP40 temperature sensor1

nxp,lpadc-temp40

on-board

NXP P3T1755 digital temperature sensor connected to I3C bus1

nxp,p3t1755

Serial controller

on-chip

NXP LPUART15

nxp,lpuart

SPI

on-chip

NXP LPSPI controller15

nxp,lpspi

on-chip

NXP FlexSPI controller1

nxp,imx-flexspi

SRAM

on-chip

Generic on-chip SRAM1

mmio-sram

Timer

on-chip

ARMv8-M System Tick1

arm,armv8m-systick

on-chip

NXP OS Timer on i.MX-RT5xx/6xx1

nxp,os-timer

USB

on-chip

NXP EHCI USB device mode1

nxp,ehci

on-chip

NXP EHCI USB host controller1

nxp,uhc-ehci

on-chip

NXP USB High Speed PHY1

nxp,usbphy

Watchdog

on-chip

LPC Windowed Watchdog Timer11

nxp,lpc-wwdt

on-chip

NXP External Watchdog Monitor1

nxp,ewm

Wakeup Controller

on-chip

NXP Wakeup Unit (WUU) acting as a Wakeup Controller (WUC)1

nxp,wuc-wuu

frdm_mcxa577/mcxa577/ns target

On-target memory for this board target: 128 KiB of RAM, 2 MiB of Flash.

Type

Location

Description

Compatible

CPU

on-chip

ARM Cortex-M33F CPU1

arm,cortex-m33f

ADC

on-chip

LPC LPADC11

nxp,lpc-lpadc

CAN

on-chip

NXP FlexCAN CANFD controller11

nxp,flexcan-fd

Clock control

on-chip

LPC SYSCON & CLKCTL IP node1

nxp,lpc-syscon

Clock monitor

on-chip

NXP Frequency Measurement (FREQME) module1

nxp,freqme

Comparator

on-chip

NXP Low Power Comparator (LPCMP)1

nxp,lpcmp

Counter

on-chip

NXP MCUX Standard Timer/Counter14

nxp,lpc-ctimer

on-chip

NXP LPTMR1

nxp,lptmr

on-chip

NXP Wake Timer1

nxp,wake-timer

CRC

on-chip

NXP CRC device1

nxp,crc

DAC

on-chip

NXP MCUX LPDAC2

nxp,lpdac

DMA

on-chip

NXP SmartDMA controller1

nxp,smartdma

on-chip

NXP MCUX EDMA controller11

nxp,mcux-edma

EDAC

on-chip

NXP Error Injection Module1

nxp,eim

on-chip

NXP Error Reporting Module1

nxp,erm

ESPI

on-chip

NXP MCX A series eSPI target controller1

nxp,espi

on-chip

NXP MCX A series eSPI Target Attached Flash (TAF) controller1

nxp,espi-taf

Ethernet

on-chip

NXP ENET QOS Ethernet Controller1

nxp,enet-qos

on-chip

Synopsys DesignWare MAC MDIO controller1

snps,dwmac-mdio

on-board

Generic MII PHY1

ethernet-phy

on-chip

Synopsys DesignWare MAC PTP (Precision Time Protocol) Clock1

snps,dwmac-ptp-clock

on-chip

NXP 10BASE-T1S PHY support1

nxp,t1s-phy

Flash controller

on-chip

NXP MSF1 Flash Memory Module (FMU)1

nxp,msf1

GPIO & Headers

on-chip

Kinetis GPIO6

nxp,kinetis-gpio

on-board

GPIO pins exposed on NXP LCD 8080 interface (e.g., used on LCD-PAR-035 panel)1

nxp,lcd-8080

on-board

GPIO pins exposed on Arduino Uno (R3) headers1

arduino-header-r3

Hardware information

on-chip

NXP LPC 128-bit Unique identifier1

nxp,lpc-uid

I2C

on-chip

NXP LPI2C controller23

nxp,lpi2c

I3C

on-chip

NXP MCUX I3C controller13

nxp,mcux-i3c

Input

on-chip

NXP TSI V6 Touch Sensing Input Device1

nxp,tsi-input

on-board

Group of GPIO-bound input keys1

gpio-keys

Interrupt controller

on-chip

ARMv8-M NVIC (Nested Vectored Interrupt Controller)1

arm,v8m-nvic

LED

on-board

Group of GPIO-controlled LEDs1

gpio-leds

MIPI-DBI

on-chip

NXP FlexIO LCD controller1

nxp,mipi-dbi-flexio-lcdif

Miscellaneous

on-chip

NXP FlexIO controller1

nxp,flexio

MMU / MPU

on-chip

ARMv8-M MPU (Memory Protection Unit)1

arm,armv8m-mpu

MTD

on-board

NXP FlexSPI NOR1

nxp,imx-flexspi-nor

on-board

Flash node2

soc-nv-flash

MUX

on-chip

NXP INPUTMUX peripheral binding1

nxp,inputmux

Pin control

on-chip

NXP PORT Pin Controller6

nxp,port-pinmux

on-chip

NXP PORT Pin Controller1

nxp,port-pinctrl

Power management

on-chip

NXP Smart Power Switch (VBAT)1

nxp,vbat

on-chip

NXP Core Mode Controller (CMC)1

nxp,cmc

on-chip

NXP System Power Control (SPC)1

nxp,spc

Power domain

on-chip

This power domain will Turn On and Off devices when transitioning in and out a specified Power State1

power-domain-soc-state-change

PWM

on-chip

NXP Flexio PWM controller1

nxp,flexio-pwm

Regulator

on-chip

NXP SPC buffered bandgap output1

nxp,spc-bandgap-buffer

Reset controller

on-chip

NXP MRCC Peripheral reset controller1

nxp,mrcc-reset

RNG

on-chip

Kinetis TRNG (True Random Number Generator)1

nxp,kinetis-trng

RTC

on-chip

IRTC1

nxp,irtc

Sensors

on-chip

NXP LPADC_TEMP40 temperature sensor1

nxp,lpadc-temp40

on-board

NXP P3T1755 digital temperature sensor connected to I3C bus1

nxp,p3t1755

Serial controller

on-chip

NXP LPUART24

nxp,lpuart

SPI

on-chip

NXP LPSPI controller15

nxp,lpspi

on-chip

NXP FlexSPI controller1

nxp,imx-flexspi

SRAM

on-chip

Generic on-chip SRAM1

mmio-sram

Timer

on-chip

ARMv8-M System Tick1

arm,armv8m-systick

on-chip

NXP OS Timer on i.MX-RT5xx/6xx1

nxp,os-timer

USB

on-chip

NXP EHCI USB device mode1

nxp,ehci

on-chip

NXP EHCI USB host controller1

nxp,uhc-ehci

on-chip

NXP USB High Speed PHY1

nxp,usbphy

Watchdog

on-chip

LPC Windowed Watchdog Timer11

nxp,lpc-wwdt

on-chip

NXP External Watchdog Monitor1

nxp,ewm

Wakeup Controller

on-chip

NXP Wakeup Unit (WUU) acting as a Wakeup Controller (WUC)1

nxp,wuc-wuu

Shields for Supported Features

Some features in the table above are tested with Zephyr shields. These shields are tested on this board:

  • NXP LCD_PAR_S035 TFT LCD Module - supports the Display interface. This board uses the MIPI_DBI interface of the shield, connected to the FlexIO on-chip peripheral.

Display Support

The frdm_mcxa577 board supports the following in-tree display module(s).

NXP LCD_PAR_S035

The NXP LCD_PAR_S035 TFT LCD Module connects to the board’s LCD socket, and is driven over the MIPI_DBI 8080 parallel interface using the FlexIO on-chip peripheral. The display sample can be built for this module like so:

west build -b frdm_mcxa577 --shield lcd_par_s035_8080 samples/drivers/display

Connections and IOs

The MCX-A577 SoC has 5 gpio controllers and has pinmux registers which can be used to configure the functionality of a pin.

Name

Function

Usage

PIO1_8

UART

UART RX

PIO1_9

UART

UART TX

System Clock

The MCX-A577 SoC is configured to use FRO LF running at 12MHz as a source for the system clock.

Serial Port

The FRDM-MCXA577 SoC has 6 LPUART interfaces for serial communication. LPUART1 is configured as UART for the console.

Ethernet

Support for two Ethernet options: the on-SoC 10BASE-T1S PHY with its on-board PMD transceiver, and a 10/100 Mbit external PHY over MII.

10BASE-T1S (default)

The default target frdm_mcxa577/mcxa577 uses the on-SoC 10BASE-T1S PHY:

# From the root of the zephyr repository
west build -b frdm_mcxa577 samples/net/zperf

10BASE-T1S Board-to-Board Setup

Two boards can be connected directly with a twisted pair between their 10BASE-T1S connectors. Exactly one node on the segment must be the PLCA coordinator (node ID 0), and the boards need different MAC addresses. The board devicetree uses PLCA node ID 1 and a random MAC address, which is identical on every board when CONFIG_TEST_RANDOM_GENERATOR is enabled, as in zperf: Network Traffic Generator.

Build the first board with the default configuration (192.0.2.1). For the second board, save the following overlay as samples/net/zperf/t1s_node0.overlay:

&enet {
    /delete-property/ zephyr,random-mac-address;
    local-mac-address = [00 04 9f 00 00 01];
};

&t1s {
    plca-enable;
    plca-node-id = <0>;
    plca-node-count = <2>;
    plca-burst-count = <0>;
    plca-burst-timer = <0x80>;
    plca-to-timer = <0x20>;
    status = "okay";
};

and the following as samples/net/zperf/t1s_node0.conf to swap the IP addresses:

CONFIG_NET_CONFIG_MY_IPV6_ADDR="2001:db8::2"
CONFIG_NET_CONFIG_PEER_IPV6_ADDR="2001:db8::1"
CONFIG_NET_CONFIG_MY_IPV4_ADDR="192.0.2.2"
CONFIG_NET_CONFIG_PEER_IPV4_ADDR="192.0.2.1"

Then build the second board with both files:

# From the root of the zephyr repository
west build -b frdm_mcxa577 samples/net/zperf -- -DEXTRA_DTC_OVERLAY_FILE=t1s_node0.overlay -DEXTRA_CONF_FILE=t1s_node0.conf

After flashing, net iface must show a different Link addr on each board, and net ping 192.0.2.2 from the first board must succeed.

External PHY over MII

The frdm_mcxa577/mcxa577/mii variant uses the external 10/100 Mbit PHY:

# From the root of the zephyr repository
west build -b frdm_mcxa577/mcxa577/mii samples/net/zperf

MII needs P1_8/P1_9 for ENET0_TXD2/TXD3, which are also the LPUART1 MCU-Link VCOM pins. The variant therefore disables LPUART1 and moves the console/shell to LPUART2 (Arduino D0/D1 header, P2_11/P2_10); connect a USB-to-serial adapter there to get console output.

The MII signals reach the external PHY only after the following solder-jumper rework (this rework is not applicable to 10BASE-T1S mode):

  • Short 2-3 (and disconnect 1-2) of SJ13 (TXD2), SJ14 (TXD3), SJ16 (RXD2), SJ17 (RXD3), SJ18 (COL), SJ19 (CRS).

  • Disconnect 1-2 and 2-3 of SJ15 (RX_CLK) and SJ44 (RXER).

Power Management

Enable CONFIG_PM to use System Power Management. The SoC PM hooks implement the following state mapping:

Zephyr state

NXP power mode

Availability

runtime-idle

Sleep

Available with CONFIG_PM

suspend-to-idle

Deep Sleep

Available with CONFIG_PM

standby

Power Down

Available with CONFIG_PM

suspend-to-ram

Deep Power Down

Disabled by default in the SoC devicetree

The PM policy chooses among enabled states according to the expected idle duration, latency constraints, and power-state locks. The devicetree residency and exit-latency values are configuration defaults, not measured guarantees for every application.

Wakeup and Timekeeping

When SysTick is the kernel timer, it stops while the core clock is gated. The board selects LPTMR0 through zephyr,system-timer-companion to keep time and provide timed wakeups. Keep the companion timer enabled and use a clock source that operates in the intended power mode. Other kernel timer configurations must also provide timekeeping and wakeups across that mode.

The wakeup-button alias describes a button’s wakeup-ctrls connection to the WUU. The alias alone does not arm a wakeup: enable the source through the WUC API before entering low power. The button and WUU pin are listed below.

Deep Power Down

Suspend-to-RAM is opt-in. Before enabling the deeppowerdown devicetree node in an application overlay, place the entire retained working set, including stacks, kernel objects, and saved CPU context, in RAM that survives this mode and arm a wakeup source. Enabling the node with CONFIG_PM also enables CONFIG_PM_S2RAM when supported by the architecture. The NXP MCX suspend-to-RAM sample provides timer and button wakeup configurations and board-specific memory layouts.

Deep Power Down resets the CORE domain and its peripheral register blocks. Applications relying on peripheral recovery must enable CONFIG_PM_DEVICE and the required power-domain support, and use drivers that restore their hardware after power loss. System-managed device PM and runtime device PM are separate mechanisms; CONFIG_PM alone does not ensure peripheral recovery.

With CONFIG_POWEROFF, system off also enters Deep Power Down, but wakeup starts through the reset path rather than resuming the suspended application. See NXP MCX system off.

Debugging and Validation

Use CONFIG_SOC_FAMILY_MCXA_DEBUG_IN_LOW_POWER or CONFIG_SOC_FAMILY_MCXN_DEBUG_IN_LOW_POWER, as appropriate, to keep debug logic enabled in modes that retain the CORE domain, at the cost of higher low-power current. Deep Power Down loses the debug connection regardless of this option.

The tests/subsys/pm/power_mgmt_soc test covers the targets in its platform allow list. Its default configuration does not enable Deep Power Down. Validate the optional state with the S2RAM sample, then verify wakeup and peripheral operation with the application’s own configuration. A sample or test target listing is not evidence of measured power consumption.

Board-specific Requirements

The wakeup-button alias selects SW2 on P3_17, routed to WUU external pin 26 with a falling-edge interrupt.

Deep Power Down can retain SRAM arrays A0 and A3 through the VBAT backup SRAM regulator, not the board’s full RAM allocation. The samples/boards/nxp/mcxn_a/s2ram/boards/frdm_mcxa577.overlay limits zephyr,sram to A3, 16 KB at 0x20004000, so the entire retained working set fits in a retainable array. Use this layout as a starting point and check the application’s RAM usage before enabling suspend-to-RAM.

Programming and Debugging

The frdm_mcxa577 board supports the runners and associated west commands listed below.

flash debug rtt reset attach debugserver
jlink ✅ ✅ ✅ ✅ ✅ ✅
linkserver ✅ (default) ✅ (default) ✅ ✅
pyocd ✅ ✅ ✅ ✅ ✅ ✅

Build and flash applications as usual (see Building an Application and Run an Application for more details).

Configuring a Debug Probe

A debug probe is used for both flashing and debugging the board. This board is configured by default to use the MCU-Link CMSIS-DAP Onboard Debug Probe.

Using LinkServer

Linkserver is the default runner for this board, and supports the factory default MCU-Link firmware. Follow the instructions in MCU-Link CMSIS-DAP Onboard Debug Probe to reprogram the default MCU-Link firmware. This only needs to be done if the default onboard debug circuit firmware was changed. To put the board in ISP mode to program the firmware, short jumper JP4.

Configuring a Console

Connect a USB cable from your PC to J13, and use the serial terminal of your choice (minicom, putty, etc.) with the following settings:

  • Speed: 115200

  • Data: 8 bits

  • Parity: None

  • Stop bits: 1

Flashing

Here is an example for the Hello World application.

# From the root of the zephyr repository
west build -b frdm_mcxa577 samples/hello_world
west flash

Open a serial terminal, reset the board (press the RESET button), and you should see the following message in the terminal:

*** Booting Zephyr OS build v3.6.0-4478-ge6c3a42f5f52 ***
Hello World! frdm_mcxa577/mcxa577

Debugging

Here is an example for the Hello World application.

# From the root of the zephyr repository
west build -b frdm_mcxa577/mcxa577 samples/hello_world
west debug

Open a serial terminal, step through the application in your debugger, and you should see the following message in the terminal:

*** Booting Zephyr OS build v3.6.0-4478-ge6c3a42f5f52 ***
Hello World! frdm_mcxa577/mcxa577

10BASE-T1S Throughput Tuning

10BASE-T1S is a shared bus arbitrated by PLCA, so the usable UDP throughput on the default frdm_mcxa577/mcxa577 target is lower than the 10 Mbps line rate. Near that limit the default network buffer sizing can be exhausted faster than the driver drains it, and packets are dropped with -EBUSY.

Increasing the net_buf fragment size, the packet and buffer pools, and the network TX/RX thread stacks avoids the drops:

CONFIG_NET_BUF_DATA_SIZE=512
CONFIG_NET_PKT_RX_COUNT=48
CONFIG_NET_PKT_TX_COUNT=48
CONFIG_NET_BUF_RX_COUNT=96
CONFIG_NET_BUF_TX_COUNT=96
CONFIG_NET_TX_STACK_SIZE=2048
CONFIG_NET_RX_STACK_SIZE=2048

These raise RAM usage, so they are applied per application rather than enabled by default. For zperf: Network Traffic Generator they are set in samples/net/zperf/boards/frdm_mcxa577_mcxa577.conf.

If more headroom is needed, the ENET QoS driver’s descriptor rings and RX thread can be enlarged as well:

CONFIG_ETH_NXP_ENET_QOS_TX_BUFFER_DESCRIPTORS=32
CONFIG_ETH_NXP_ENET_QOS_RX_BUFFER_DESCRIPTORS=32
CONFIG_ETH_NXP_ENET_QOS_RX_THREAD_STACK_SIZE=2048
CONFIG_ETH_NXP_ENET_QOS_RX_THREAD_PRIORITY=2

Raising the priority of the application thread generating the traffic reduces inter-packet jitter. For zperf: Network Traffic Generator:

CONFIG_ZPERF_WORK_Q_THREAD_PRIORITY=7
CONFIG_ZPERF_WORK_Q_STACK_SIZE=4096

Troubleshooting

Using Segger SystemView and RTT

Note that when using SEGGER SystemView or RTT with this SOC, the RTT control block address must be set manually within SystemView or the RTT Viewer. The address provided to the tool should be the location of the _SEGGER_RTT symbol, which can be found using a debugger or by examining the zephyr.map file output by the linker.

The RTT control block address must be provided manually because this SOC supports ECC RAM. If the SEGGER tooling searches the ECC RAM space for the control block a fault will occur, provided that ECC is enabled and the RAM segment being searched has not been initialized to a known value.

Support Resources for Zephyr
