MikroElektronika 3 axis Accel 4 Click
Overview
Accel 4 Click is a sensing Click board™, equipped with the FXLS8974CF, a 3 axis accelerometer sensor.
This IC has a separate sensing element on each axis, which allows a very accurate and reliable measurement of the acceleration intensity in a 3D space, offering a basis for accurate positional calculations. Both I2C and SPI communication protocols are supported by the FXLS8974CF. This sensor IC features a powerful programmable interrupt engine, allowing firmware optimization.
Accel 4 Click
Requirements
This shield can only be used with a board that provides a mikroBUS™ socket and defines a
mikrobus_i2c node label for the mikroBUS™ I2C interface. See Shields for more details.
Programming
Set --shield mikroe_accel4_click when you invoke west build. For example:
# From the root of the zephyr repository
west build -b frdm_mcxn947/mcxn947/cpu0 --shield mikroe_accel4_click samples/sensor/accel_polling
west flash
See nxp,fxls8974 for documentation on the additional binding properties available for
the FXLS8974CF sensor.
